PRODUCT DISCONTINUED: Information provided is for reference only

Nonincendive Bluetooth -Compatible, Wireless Industrial Keyboard With Touchpad From iKey Keyboards

BT-87-TP-NI Features

  • Non-Incendive For Hazardous Environments
  • Bluetooth - Compatible Version 2.0
  • Up To 30-Foot Range
  • Integrated Touchpad
  • Various Keyboard and Language Layout Options

BT-87-TP-NI Keyboard Options



PRODUCT DISCONTINUED: Information provided is for reference only

The BT-87-TP-NI is a Bluetooth -compatible, Nonincendive keyboard built for use in hazardous locations and is FM-approved for Class I, Division II, Groups A, B, C and D.

This fully-sealed keyboard is designed to meet NEMA 4X specifications, meaning it is resistant to dirt, dust, water, ice and corrosives. Built with an industrial silicone rubber keypad and a rugged ABS polycarbonate case, the BT-87-TP-NI is submersible and easy to clean with disinfectants. The compact design, integrated touchpad and internal Bluetooth module make the BT-87-TP-NI highly portable.

The BT-87-TP-NI requires 2 AA batteries for power and does not require a USB dongle if your computer has an internal Bluetooth radio.

Specification
Manufacturer or Brand iKey
Mounting Format Desktop, Free Standing
IP Rating IP66
Interface Bluetooth
Case Material ABS Polycarbonate
Housing Colour Black
Backlight No Backlight
Certifications IP Rated, NEMA 4X, CE UL60950, FCC Part 15, Class B Factory Mutual Class I, Division II, Groups A, B, C and D
Temperature Rating STORAGE: -40C to +65C (-40F to +149F) OPERATING: 0C to +60C (+32F to +140F)
Humidity 100% Humidity Resistant
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 12.01" x 7.75" x 2.03" (w-h-d) 305.54 mm x 196.85 mm x 51.56 mm
Warranty 1 Year Limited Warranty
Cable LENGTH: 5.4' straight (1.6 m) DESIGN: Single cable USB
Compatibility All Windows OS
Connectivity Wireless , Bluetooth
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 12 Keys
Key Feedback Tactile with Mechanical Snap
Key Material Industrial Silicone Rubber
Key Switch MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4 mm) ACTUATION FORCE: 7.03 oz +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Lifespan >10 Million Actuations
Mounting Filter Desktop
No. Of Keys 87
Pointing Device Touchpad
Power Bluetooth : 2 AA Batteries
Product Weight 2.00 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force 200g (+/- 30g)
Switch / Key Travel 0.055 in (1.4mm)
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • Non-Incendive For Hazardous Environments
  • Bluetooth - Compatible Version 2.0
  • Up To 30-Foot Range
  • Integrated Touchpad
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey BT-87-TP-NI is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey BT-87-TP-NI Keyboard are listed below:-

  • Factory Floor
  • Hazardous Location
  • Industrial Automation
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the iKey BT-87-TP-NI Keyboard The potential applications extend further than those shown above. For further information about the iKey BT-87-TP-NI Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the iKey BT-87-TP-NI Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey BT-87-TP-NI Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey BT-87-TP-NI Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)
