DU-5K-OEM-FSR USB DU-5K-OEM-FSR PS2 DU-5K-OEM-FSR FORCE-SENSING-RESISTOR DU-5K-OEM-FSR DUSTPROOF DU-5K-OEM-FSR CUSTOMISABLE


iKey-DU-5K-OEM-Keyboard

DU-5K-OEM iKey Keyboard

iKey-KYB-114-OEM-Keyboard

KYB-114-OEM iKey Keyboard

DU-5K-OEM-FSR iKey Keyboard

Introducing the DU-5K-FSR-OEM, an OEM keyboard from iKey® that's designed to meet the needs of the most demanding users. This rugged OEM keyboard features a newly improved integrated force sensing resistor pointing device, providing the user with seamless and efficient navigation. The DU-5K-FSR-OEM is an exceptional tool that comes with 24 function keys and a 10-key number pad, offering comprehensive control and data input options.

DU-5K-OEM-FSR Features

  • Industrial Silicone Rubber Keypad
  • Integrated Force Sensing Resistor
  • Meets NEMA 4X (IP65) Specifications
  • 10-Key Numeric Pad
  • Various Keyboard and Language Layout Options

DU-5K-OEM-FSR Keyboard Options



Introducing the DU-5K-FSR-OEM, an Rugged OEM keyboard from iKey® that's designed to meet the needs of the most demanding users. This keyboard features a newly improved integrated force sensing resistor pointing device, providing the user with seamless and efficient navigation. The DU-5K-FSR-OEM is an exceptional tool that comes with 24 function keys and a 10-key number pad, offering comprehensive control and data input options.

The DU-5K-FSR-OEM is designed to meet NEMA 4X specifications, which means it offers a level of protection against dust, water, and other elements when properly installed. It's available in PS/2 or USB configurations, catering to a wide array of user preferences.

One of the highlights of this keyboard is its industrial silicone rubber keypad, which provides a durable and comfortable typing experience. With a lifespan greater than 10 million cycles and a tactile feedback with a mechanical snap, this keyboard is built to last.

The DU-5K-FSR-OEM is versatile and resilient, capable of withstanding a range of environmental conditions. It can tolerate shock pulses of 50g on each of 3 axes and has a storage temperature range of -40°C to 85°C. It's also fully resistant to 100% humidity, making it a great choice for humid environments.

The keyboard comes with a long 10-feet cable and is compatible with all Windows operating systems via PS/2, and with all Windows and Macintosh OS via USB. It's lightweight, weighing only 1.50 lbs (0.68 kg), and has compact dimensions of 14.75" x 6.43" x 0.35" (w-h-d) or 374.7mm x 163.3mm x 8.9mm.

Customers have praised the DU-5K-FSR-OEM for its quality and reliability, with many highlighting its suitability for both commercial and rugged environments. It's a keyboard that you can count on, from a company that values professionalism and customer satisfaction.

Specification
Manufacturer or Brand iKey
Mounting Format OEM
IP Rating IP68
Interface PS2, USB
Case Material No Case
Backlight No Backlight
Certifications NEMA 4X, CE UL60950, FCC Part 15, Class B
Temperature Rating STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)
Humidity 100% Humidity Resistant (when properly installed)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 14.75" x 6.43" x 0.35" (w-h-d) 374.7mm x 163.3mm x 8.9mm
Warranty 90 Day Limited Warranty
Cable Single-Cable USB or PS2
Compatibility All Windows and Macintosh Operating Systems
Connectivity No filter
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 24 Keys
Key Feedback Tactile with Mechanical Snap
Key Material Industrial Silicone Rubber
Key Switch MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. ACTUATION FORCE: 180g FEEDBACK: Tactile with Mechanical Snap
Lifespan >10 Million Actuations
Mounting Filter Desktop
No. Of Keys 116
Pointing Device Force Sensing Resistor
Power PS/2: KEYBOARD: 50mA@5V (from Keyboard port) POINTER: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port)
Product Weight 1.50 lbs (0.68 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force 180g (+/- 30g)
Switch / Key Travel 0.055 in (1.4mm)
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • Industrial Silicone Rubber Keypad
  • Integrated Force Sensing Resistor
  • Meets NEMA 4X (IP65) Specifications
  • 10-Key Numeric Pad
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey DU-5K-OEM-FSR is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey DU-5K-OEM-FSR Keyboard are listed below:-

  • Broadcast Consoles
  • Factory Floor
  • Helicopter Consoles
  • Industrial Automation
  • Marine Consoles
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the iKey DU-5K-OEM-FSR Keyboard The potential applications extend further than those shown above. For further information about the iKey DU-5K-OEM-FSR Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the iKey DU-5K-OEM-FSR Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey DU-5K-OEM-FSR Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey DU-5K-OEM-FSR Keyboard has a 90 Day Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey DU-5K-OEM-FSR Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
