RKP-A160-38-TB RUGGED Keypad

IP65 static rated Vandal proof Stainless Steel industrial Trackball with IP65 static 38mm trackball module with integrated numeric keypad

RKP-A160-38-TB Features

  • Rugged Panel Mount Keypad
  • Integrated Trackball
  • IP65 Rated
  • Stainless Steel Construction

RKP-A160-38-TB Keypad Options



IP65 static rated Vandal proof Stainless Steel industrial Trackball with IP65 static 38mm trackball module with integrated numeric keypad with industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise, 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling, stainless steel top plate with threaded bolts for top panel mounting solution. Dimensions: 160.0mm x 125.0mm (top panel)

Specification
Manufacturer or Brand RUGGED
Mounting Format Panel Mount
IP Rating IP65
Interface PS2, RS232, USB
Case Material Stainless Steel
Housing Colour Stainless Steel
Certifications RoHS Compliant, CE and FCC, ESD
Temperature Rating STORAGE: 30C to +70C OPERATING: :-20C to +60C
Dimensions 160.0mm x 125.0mm (front panel), 140.0mm x 105.0mm (back panel)
Width 125.0mm
Length 160.0mm
Warranty 1 Year Limited Warranty
Compatibility All Windows, Linux, Unix, Mac OSX, Vxworks, Android
EMC EMC directive 89/336/EEC EN55022:1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003
EMI EN 50081-1
EMS EN 55024:2010
Frontplate Material Super Quality Brushed Stainless Steel
Key Material super quality brushed stainless steel
Lifespan > 5 years
Mounting Filter Panel Mount
MTBF  >50000H
MTTR <30min
No. Of Keys 21
Operating Force 0.6 N+/-0.1N for key 14.0mm x 14.0mm (pressure point) 1.2 N +/-0.1N for key 14.0mm x 28.0mm (pressure point)
Pointing Device Trackball
Power +5V DC +/-5%
Product Weight 1.0Kg.
Resolution 440 edges/revolution
Supply Current appr. 30mA
Supply Voltage +5V DC +/-5%
Switch / Key Travel 2.0mm
Trackball Diameter 38mm (1.5') diameter
  • Rugged Panel Mount Keypad
  • Integrated Trackball
  • IP65 Rated
  • Stainless Steel Construction
The RUGGED RKP-A160-38-TB is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKP-A160-38-TB Keypad are listed below:-

  • Access Control
  • Broadcast Consoles
  • Computer Consoles
  • Industrial Automation
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the RUGGED RKP-A160-38-TB Keypad The potential applications extend further than those shown above. For further information about the RUGGED RKP-A160-38-TB Keypad or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RUGGED RKP-A160-38-TB Keypad to suit your requirements. These options include:

  • Cable Type
  • Cable Length
  • Interface
  • Keypad Layout

If your application requires unusual or individual modifications not listed above for the RUGGED RKP-A160-38-TB Keypad, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RUGGED RKP-A160-38-TB Keypad has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RUGGED RKP-A160-38-TB Keypad, must be presented to us here in the UK.
