RKP-B75 RUGGED Keypad
16 keys MINI IP65 dynamic waterproof and vandal proof Stainless Steel industrial numeric keypad with industrial electronics controller shielded & protected by stainless steel housing
RKP-B75 Features
- Rugged Panel Mount Keypad
- IP65 Rated
- Stainless Steel (Black) Construction
16 keys MINI IP65 dynamic waterproof and vandal proof Stainless Steel industrial numeric keypad with industrial electronics controller shielded & protected by stainless steel housing, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, top stainless steel plate with welded studs for top panel mounted.
Dimensions: 75.0mm x 73.0mm (top panel)
| Manufacturer or Brand | RUGGED |
|---|---|
| Mounting Format | Panel Mount |
| IP Rating | IP65 |
| Interface | PS2, USB |
| Case Material | Stainless Steel |
| Certifications | RoHS Compliant, CE and FCC, ESD |
| Operating Temperature | Operating temperature:-20C to +60C |
| Storage Temperature | Storage temperature: -30C to +70C |
| Temperature Rating | Operating temperature:-20C to +60C - Storage temperature: -30C to +70C |
| Humidity | 30-90% Humidity Resistant |
| Dimensions | 75.0mm x 73.0mm |
| Width | 73.0mm |
| Length | 75.0mm |
| Warranty | 1 Year Limited Warranty |
| Base plate Material | Epoxy resin gilding |
| Compatibility | All Windows and Macintosh Operating Systems |
| EMC | IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004 |
| EMI | EN 55022: 2010 |
| EMS | EN 55024:2010 |
| Frontplate Material | Brushed Stainless Steel |
| Key Material | Stainless Steel |
| Key Switch | Gold-on-Gold key Switch Technology |
| Lifespan | > 5 years |
| Material (Bottom Plate) | Natural Electrical Conductive Silicon Rubber |
| Mounting Filter | Panel Mount |
| MTBF | >50000h |
| MTTR | <30min |
| No. Of Keys | 16 |
| Operating Force | 1.0N +/-0.1N (pressure point) |
| Supply Current | Under 300mW for operation, under 200mW for non-operation |
| Supply Voltage | +5V DC +/-5% |
| Switch / Key Travel | 0.45mm |
- Rugged Panel Mount Keypad
- IP65 Rated
- Stainless Steel (Black) Construction
The RUGGED RKP-B75
is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKP-B75 Keypad are listed below:-
These are just some of the applications for the RUGGED RKP-B75 Keypad The potential applications extend further than those shown above. For further information about the RUGGED RKP-B75 Keypad
or to check if the product is suitable for your application, please do not hesitate to contact us.
- Access Control
- Broadcast Consoles
- Computer Consoles
- Industrial Automation
- Smart Factory
- Industry 4.0
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RUGGED RKP-B75 Keypad to suit your requirements. These options include:
If your application requires unusual or individual modifications not listed above for the RUGGED RKP-B75 Keypad, please contact us with your exact requirements and we will help create a custom solution to meet your needs.
- Cable Type
- Cable Length
- Interface
- Keypad Layout
The RUGGED RKP-B75 Keypad has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)
To obtain service under this warranty, the warranty-eligible product, RUGGED RKP-B75 Keypad, must be presented to us here in the UK.
For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
